Measurement Range |
-0.1．．．0~0.01．．．~100MPa |
|
Proof pressure |
≤1.5X rated pressure or 110MPa which ever is less |
|
Pressure type |
Gauge, absolute ,sealed gauge |
|
Accuracy |
±0.1% ±0.25%（Typical） |
|
Long term stability |
±0.5%F.S/year |
|
Zero temperature Drift |
±0.03%F.S/℃（≤100KPa） ±0.02%F.S/℃（＞100KPa） |
|
Span temperature Drift |
±0.03%F.S/℃（≤100KPa） ±0.02%F.S/℃（＞100KPa） |
|
OperatingTemperatureRange |
-20℃~80℃ |
|
Storage TemperatureRange |
-40℃~120℃ |
|
Power supply |
24VDC（15～30）VDC |
|
Output signal |
Analog output:4～20mA 0～10mA 1～5VDC 0～5VDC |
|
|
Digit output: HART protocol RS485 protocol digit signal output |
|
Pressure port |
M20×1.5 G1/2 or customize |
|
Display |
-1999～9999 |
|
Housing material |
1Cr18Ni9Ti stainless steel |
|
Diaphragm material |
316L |
|
O-ring |
Fluororubber |
|
Cable |
polyethylene |
|
Insulation resistance |
100MΩ 100VDC |
|
Protection |
IP65 |
a: Range?
b: Accuracy?
c: Pressure port?
d: Electrical connection?
e: Output signal?
f: Power supply?
g: Your working media?
h: Your working temperature?
i: Need a cable? Cable length?
